Surly Bridge Club
Test en bestel!
€ 1.599,00
Artikelnummer:
Black
"Surly Bridge Club Bike - 650b - Trevor's Closet Black"
As a highly versatile touring bike, the Bridge Club hits the sweet spot that separates on- and off-road excursions. The simplistic design makes it fully adept to handle a full rack and pannier setup, frame bags, or any combination of the two. It doesn’t feel sluggish on paved shortcuts, but can also hold its own on dirt detours. If you’re feeling a little zesty on your next road tour, you won’t be ill-prepared for reroutes through the woods. The Bridge Club is designed to handle it all.
- 100% Surly Chromoly frame, main triangle is double-butted; 1-1/8" threadless Chromoly fork
- Rack, fender, and four sets of three-pack mounts
- Disc brake-specific, single-position vertical rear dropout makes it less intimidating than other bikes in the category
- Clearance for 700 x 47mm (with or without fenders) or 27.5 x 2.8" tires (27.5 x 2.6" with fenders)
- Shimano 1x11 Cues Drivetrain
- Shimano Cues U6000 GS Rear Derailleur with Shimano Cues LG400, 11-50t, 11spd Casette
- Brakes: Tektro HD-M275/HD-M276, 2 piston, Tektro 160/160 rotors, 6-Bolt
- Handlebar: Salsa Bend
- Wheels: Novatec Hubs, QR x 100/141mm, 6 bolt, 32h with WTB i30 Rims
- Tires: WTB Trail Boss 27.5 x 2.4", 27 tpi, Wire Bead
Niet je maat gevonden? Stuur een bericht!
Not your size? Contact us!
Pedals for Surly Bridge Club
Surly Bridge Club Specs
| Frame | Surly Bridge Club - 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated |
| Color | Black |
| Fork | Surly Cocktail Fork - 4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated |
| Headset | Cane Creek |
| Seatpost Clamp | Surly Stainless 30.0 |
| Seatpost | Promax 27.2mm |
| Stem | Promax, 31.8mm |
| Grips/Bar Tape | Velo Black |
| Saddle | WTB Volt |
| Handlebar | Salsa Bend |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano Deore RD-M5100, Shadow Plus |
| Cassette | Shimano Deore 11-speed, 11-51t |
| Chain | KMC X11 |
| Crankset | Shimano Deore FC-M5100, 32t |
| Shifter | Shimano Deore SL-M5100-R |
| Brake Levers | Tektro HD-M275/276 |
| Bottom Bracket | Shimano |
| Rotors | Tektro 160/160, 6-Bolt |
| Front Tire | WTB Trail Boss 27.5 x 2.4", 27tpi, Tubeless Ready |
| Rear Tire | WTB Trail Boss 27.5 x 2.4", 27tpi, Tubeless Ready |
| Front Hub | Novatec, QR x 100mm, 6 bolt, 32h |
| Rear Hub | Novatec, QR x 141mm, 6 bolt, 32h |
| Rim | WTB ST i29 TCS |
Bridge Club Geometry
| Size | X-Small | Small | Medium | Large | X-Large |
| A. Effective Top Tube | 545.0 | 570.0 | 595.0 | 615.0 | 630.0 |
| B. Stand Over | 709.0 | 750.5 | 780.0 | 812.0 | 845.5 |
| C. Reach | 376.0 | 397.0 | 419.0 | 434.5 | 444.0 |
| D. Stack | 553.0 | 567.0 | 576.0 | 590.0 | 609.0 |
| E. Total Seat Tube Length | 335.6 | 406.4 | 457.2 | 508.0 | 558.8 |
| F. Headtube Length | 110.0 | 120.0 | 130.0 | 145.0 | 165.0 |
| G. Headtube Angle | 70.0 | 71.0 | 71.0 | 71.0 | 71.0 |
| H. Seat Tube Angle | 73.0 | 73.0 | 73.0 | 73.0 | 73.0 |
| I. BB Drop | 60.0 | 60.0 | 60.0 | 60.0 | 60.0 |
| K. Chainstay Length | 435.0 | 435.0 | 435.0 | 435.0 | 435.0 |
| L. Fork Length Axle to Crown | 420.0 | 420.0 | 420.0 | 420.0 | 420.0 |
| M. Fork Offset | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 |
| N. Wheelbase | 1032.0 | 1047.5 | 1073.0 | 1093.0 | 1109.0 |
| Crank Arm Length | 170.0 | 170.0 | 175.0 | 175.0 | 175.0 |
| Handlebar Width | 700.0 | 700.0 | 740.0 | 740.0 | 740.0 |
| Recommended Rider Height | 145.0 - 160.0 | 155.0 - 170.0 | 165.0 - 180.0 | 175.0 - 191.0 | 185.0 - 201.0 |
| Stem Length | 90.0 | 90.0 |
